Technical specifications


Principle
  • 2 way coaxial system
Power Handling
  • 60 / 240 Watt
Impedance
  • 4 Ohms
Crossover frequencies
  • 4200 Hz
Frequency range
  • 38 – 24000 Hz
Sound pressure level
  • 89 dB
DIN-Ø
  • 0.5” mm tweeter
  • Woofer: 4”
Outer diameter
  • 142 mm
Cutting out
  • 94 mm
Mounting depth
  • 50 mm
Mounting hight
  • 20 mm

Highlights


Features
  • Magnet protection cover in Mac Audio design
  • Long excursion rubber surround
  • Polypropylene cone with titanium hairline finish
  • Suspension and magnetic field optimised with KLIPPEL® measurement system
Principle
  • 2 way coaxial system
Membrane capacity
  • Titanium coated polycarbonate
  • Woofer: Injection Polypropylene
